Fibreheart PPA-CF Carbon Fiber Nylon | Industrial Grade
Fibreheart PPA-CF Carbon Fiber Nylon | Industrial Grade
Regular price
$64.99 USD
Regular price
Sale price
$64.99 USD
Quantity
Couldn't load pickup availability
Fibreheart PPA-CF is the most extreme filament we carry. Polyphthalamide with carbon fiber delivers unmatched heat and chemical resistance — capable of replacing metal parts in non-critical applications.
- Best for: Metal replacement, chemical exposure, sustained 200°C+ environments
- Heat resistance: >250°C
- Impact strength: Moderate — stiff and strong but less ductile
- Chemical resistance: Outstanding — insoluble in nearly all solvents below 200°C
- Print difficulty: Expert only — 300-320°C, zero cooling, brim mandatory, 120°C drying
Print Settings (enclosed printer / 0.6mm HF / Chamber Heater)
Nozzle: 0.6mm Hardened Steel | ZERO COOLING - any fan causes delamination
| Nozzle Temp | 300-320C |
| Bed Temp | 110-120C |
| Chamber Temp | 55-60C (soak 20+ min) |
| Dry Temp / Time | 120C for 12 hours (MANDATORY) |
| Flow Ratio | 0.96 |
| Max Vol Flow | 11-15 mm3/s |
| Max Cooling | 0% |
| Retraction | 0.3mm at 18mm/s |
| Outer Wall Speed | 35-45 mm/s |
| Bed Prep | Glue stick + BRIM REQUIRED on ALL parts |
Check nozzle tip after every spool. PPA-CF wears steel faster than any other CF filament.
For full 4-nozzle settings card, see product images. Tested on enclosed printer with Chamber Heater.
